Elcab Conductors is foremost FLRY-B shielded cable manufacturers, suppliers in India. We are dedicated to producing a product that would greatly lower harness weight and complexity at the expense of providing better performance. Selecting our FLRY-B cable will entail investment in an electrical integrity base.

It offers unmatched adaptability in terms of easy installation and strong performance in high temperatures and high-performance car fluids. Drive with confidence- Use our FLRY-B cables that are thinner-walled and more efficient (trusted) to have a safer, light and reliable electrical system.

What is FLRY-B Shielded Cable?

The FLRY-B cable is a standardized low-voltage automotive wire that incorporates Flexible conductor (FL) with Reduced-insulation-thickness (R) using PVC (Y) material with the B denoting the flexible conductor construction (Type B stranding). The thin-wall design is important in reduction of weight and space-saving of complex vehicle wiring harnessing.

Variations of FLRY-B cable:

Being as well established FLRY-B shielded cable manufacturers in India, different variations are there which are given below.

Through cross-sectional area: The conductor thickness is one of the distinguishing factors. This may be FLRY-B0.50 (0.5mm²) and FLRY-B1.00 (1.0mm²). Even bigger sizes such as FLRY-B2.50 (2.5mm²) are possible.
By color: The cables are made in various colors to help identify them in complicated wiring harness. FLRY-B Shielded Wire Manufacturers in India, are such as brown, orange, yellow, black, violet and grey.
By type of conductor used: Although this is not a type of shielding, the conductor can be defined as stranded copper, which is flexible in FLRY-B Shielded Wire Suppliers in India.
Voltage and Insulation: All FLRY-B cables shall be low-voltage (usually 60 V DC) cables. This insulation is of a PVC based material, and a "B" denotes that a smaller insulation thickness is used, resulting in more compact and flexible cable.

Additionally, if signal integrity is a priority in your system, our Profibus Cable Manufacturers in India page provides reliable solutions for industrial communication and data systems.

Technical Specifications of FLRY-B Shielded Cable:

We've added below a specialized table of FLRY-B Shielded Cable in India that provides further technical specification information.

Feature	Specification Details
Application	Low-voltage wiring for automobiles, motorcycles, and other motor vehicles. Used in starting, charging, lighting, signal, and instrument panel circuits.
Standard Compliance	ISO 6722 Class B, DIN 72551-6, LV 112, and others may vary by manufacturer.
Construction	Single Core, Thin-Wall Insulation.
Conductor	Soft-annealed electrolytic copper Cu-ETP1, bare or tinned.
Conductor Stranding	Type B Asymmetrical/Irregular lay - Offers high flexibility.
Insulation Material	PVC Polyvinyl Chloride, Class B. Lead-free and flame retardant.
Temperature Range	−40°C to +105°C for 3,000 hours.
Rated Voltage	Typically 60 V DC suitable for 12 V and 24 V systems. Some standards may allow up to 1000 V AC/1500 V DC.
Test Voltage	3 kV for cross-section <0.5 mm²; 5 kV for cross-section ≥0.5 mm².
Key Properties	High flexibility, thin wall insulation for weight/space savings, excellent resistance to petrol, diesel, oils, acids, and abrasion.
Shielding	Unshielded - The standard FLRY-B designation does not include a shield.

Benefits/Features of FLRY-B Shielded Cable:

We as FLRY-B shielded cable suppliers in India, different benefits are there which are given below.

Excellent Space and Weight savings: The thin-wall insulation makes the overall size and weight of the cable to be extremely slim and this is important in current fuel-saving vehicle designs.
High Temperature Resistance: FLRY-B shielded cable manufacturers in India working temperature of -40°C up to +105°C, this has a continuous working range that is stable even in a hot engine compartment, and also in harsh environments.
Superior Hazard Protection: The PVC insulation is very impervious to the most frequent automotive oils (petrol, diesel, and oils) and acids ensuring high durability.
Increased Flexibility: The cable is made with fine strand copper conductor allowing superior flexibility, hence easy and efficient to install and route in tight spaces.

Key Characteristics of FLRY-B Shielded Cable:

We as well established FLRY-B shielded cable manufacturers in India, different key characteristics are there.

Thin-Wall PVC Insulation (R): Din 72551 Automotive Single Core Cable, FLRY-B Cable – Thin Wall Cable for Automotives characteristic implies that the jacket of the cable is thinner than the ordinary automotive wires, which enables lighter and smaller bundles of wires to be made.
Flexible Copper Conductor (Type B): FLRY-B shielded cable suppliers in India construction is composed of fine-stranded, soft-annealed electrolytic copper which is highly conductive and offers excellent bend radius. It is flexible and is therefore easy to install and is also resistant to overtime vibration and movement.
Large Operating Temperature: The cable is stringently tested to be of integrity in a range between extreme cold (-40°C) and extreme heat (105°C). This stability renders it ideal in diverse use in the whole vehicle, exterior and interior.
Conformity to ISO 6722/DIN 72551: Conformity to these international standards implies that the cable is of high quality in accordance to automotive cables. This will ensure safety, quality and uniform performance across the world.

Applications of FLRY-B Shielded Cable:

Serve as well established FLRY-B shielded cable suppliers in India, it is applicable in different sites which are given below.

Automobile Wiring Harnesses: Harnesses that are used as the main wiring in the low voltage signal distribution and power supply to the whole vehicle chassis.
Lighting Systems: These are needed to connect headlamps, tail lights and interior cabin light circuits.
Signal and Sensor Circuits: These are used in the transmission of data and power to other sensors, dashboard and other instrument panel components.
Starting and Charging Circuits: These are used in the circuits which supply the battery to the starter motor and alternator.
Motorcycles and Two-Wheelers: Mainly used in compact wiring systems where the weight and space of the system is very important.

Why Use Us for FLRY-B Shielded Cable?

Quality Assured: FLRY-B shielded cable manufacturers in India manufacture our cables in ISO-certified plants, where each metre is of high quality to the international automotive standards.
Installed Solutions: To meet your specifications of sizes, colours, and optional tinned-copper conductors, we have a variety of sizes, colours, and optional tinned-copper conductors, to satisfy your requirements and specifications concerning corrosion resistance.
Quality Supply Chain: We are committed manufacturers and suppliers that will deliver punctually and maintain consistent stock supply, which will not fail to support your productions.

Elcab Conductors is premier FLRY-B shielded cable manufacturers, suppliers in India. In the automotive excellence, the decision is obvious. FLRY-B shielded cable is the threefold of efficiency, strength, and flexibility like no other. It is not a simple wire, it is the nervous system of your car, designed to survive in the most adverse circumstances. FLRY-B cable works perfectly at engine heat, chemical exposures and proves to be safe and reliable mile after mile. Design your products future proof and improve your products quality- Contact us today to make sure you have the best in automotive wiring!
