Elcab Conductors is outstanding ISO 6722-C cable manufacturers, suppliers in India. It is built to withstand high temperatures of up to 125°C and ensures the continuation of power supply at where the normal cables fail. The built-in shielding protects sensitive electronics against the electromagnetic interference (EMI), guaranteeing the perfect operation of the system and transmission of data. Quit selling quality. Trust us to install cables that are of high-quality international standards, and with modern technology in vehicles, we will ensure that the technology is smoothly and safely operating at all times.
What is ISO 6722-C Cable?
The ISO 6722 is the international standard of the low voltage electrical cables in road vehicles. One type of the ISO 6722-C cable is its cable. The C classification implies that the cable has the ability to function at a maximum operating temperature of 125°C.
This high thermal rating is necessary to provide strong and safe performance in hot places such as engine bays, which is an important element in the automotive industry.
Types of ISO 6722-C Cable:
Being as recommended ISO 6722-C Cable manufacturers in India, we provided different types which are given below.
Construction and voltage classification:
- Single-core cables: Single-core cables are the ISO 6722 standard of cables utilized in vehicles with either 60 V or 600 V DC rating.
- Thin and thick wall: The cables are produced in thin and thick wall to support various flexibility and durability.
- Thin wall: Applied in automotive wiring harnesses of small size.
- Thick wall: Thick wall is also utilized to connect a battery as in the case below.
Voltage ratings:
- 60 V DC: It is used in ordinary automotive in ISO 6722-C Cable suppliers in India.
- 600 V DC: 600 V DC is applied in higher voltages used in vehicles.
To complement our ISO 6722-C cables rated for up to 125 °C, we also manufacture ultra-thin wall automotive wiring — check out our ISO 6722-D Cable Manufacturers in India for even higher temperature applications.
Technical Specifications of ISO 6722-C Cable in India:
We've added below a specialized table of ISO 6722-C Cable in India that provides further technical specification information.
| Specification |
Thin Wall FLRY-A/B equivalent |
Thick Wall FLY equivalent |
60 V DC Rating |
600 V DC Rating |
| ISO 6722 Classification |
Class C Thin Wall |
Class C Thick Wall |
Low-Voltage Standard |
High-Voltage EV/HEV |
| Max Operating Voltage |
≤60 V DC or 25 V AC Typical |
≤60 V DC or 25 V AC Typical |
≤60 V DC or 25 V AC |
>60 V DC up to 600 V DC or 600 V AC |
| Insulation Wall Type |
Thin e.g., FLRY-A/B |
Thick e.g., FLY |
N/A Applies to both |
N/A Applies to both |
| Nominal Temperature Class |
125°C Class C |
125°C Class C |
125°C Class C |
125°C or Higher e.g., Class D/E |
| Temperature Range |
−40°C to +125°C 3000 h |
−40°C to +125°C 3000 h |
−40°C to +125°C |
−40°C to +125°C |
| Test Voltage AC |
3 kV for <0.5 mm², 5 kV for ≥0.5 mm² |
3 kV for <0.5 mm², 5 kV for ≥0.5 mm² |
3 kV / 5 kV |
Up to 10 kV |
| Typical Conductor Material |
Annealed Plain or Tinned Copper Strands |
Annealed Plain or Tinned Copper Strands |
Plain/Tinned Copper |
Plain/Tinned Copper |
| Typical Insulation Material |
PVC Polyvinyl Chloride for 125°C |
PVC Polyvinyl Chloride for 125°C |
PVC |
XLPE/Silicone for ≥125°C |
| Abrasion Resistance |
Good Thin wall standard |
Higher Thick wall standard |
Standard ISO 6722 |
Must meet Thick Wall abrasion requirements |
| Common Application |
General automotive wiring harnesses for space saving |
General automotive wiring for durability, battery connections |
Ordinary 12/24V automotive systems |
Electric/Hybrid Vehicle EV/HEV power and charging circuits |
Benefits / Features of ISO 6722-C Cable:
As ISO 6722-C Cable suppliers in India, different benefits are there which are given below.
- High thermal Resistance: Superior thermal insulation has ISO 6722 Class C Wires thermal resistance that can be used to work with high temperatures up to 125°C.
- Supreme EMI Control: The internal shielding is very effective in preventing the electromagnetic interference (EMI) of the sensitive signals in ISO 6722-C Cable manufacturers in India.
- Space-Saving Design: Type C frequently represents a thinner wall thickness, so the type can be installed in a small vehicle in ISO 6722-C Wire Suppliers in India.
- Long Term Durability: Made using materials that are highly resistant to typical automotive fluids such as oil and fuels and is engineered to be resistant to abrasion.
Key Characteristics of ISO 6722-C Cable:
We as recommended ISO 6722-C Cable manufacturers in India, different key characteristics are there which are given below.
- Conductor Material: ISO 6722-C Wire Manufacturers in India, is usually made of a very flexible highly strained, fine conductor of copper, which is usually tinned to ensure better protection.
- Insulation Type: Has a high-performance, cross-linked polymer jacket, e.g. XLPE, and this is what determines its high-temperature rating. This is a material that offers thermal and mechanical toughness needed by the 125°C operating class which is very demanding.
- Shielding Construction: This type of construction incorporates a braided metal shield or a foil/braid combination layer over the insulated core.
- Voltage Rating: The standard voltage rating is only 60 V DC, but is classified as low-voltage. It is the most popular selection of all primary power and complex signal circuits in the road vehicle structure.
Applications of ISO 6722-C Cable:
We serve as recommended ISO 6722-C Cable suppliers in India, it is applicable in different sites which are given below.
- Wiring harnesses and sensor lines (e.g., near turbochargers or exhaust manifolds) of the engine.
- Signal and power connections of Electronic Control Unit where noise free transmission is critical in ISO 6722-C Cable manufacturers in India.
- ABS sensor and control lines. Electronic Braking System sensor and control lines.
- High-speed data buses such as Ethernet, Advanced Driver-Assistance Systems (ADAS).
- Modern Electric Vehicles (EVs) and Hybrid Vehicles (HVs) have Battery Management Systems (BMS) and the power supply lines.
Why Choose Us for ISO 6722-C Cable?
- Trusted Product: Our production of cables is guided by the ISO 6722-C standards that ensure uniform high-quality operation to your vital systems.
- Thermal Expertise: We have specialized in high-temperature and durable insulation products and made sure that your electrical systems are secure and stable under harsh conditions.
Elcab Conductors is foremost ISO 6722-C cable manufacturers, suppliers in India. As the leaders of shielding and screening cable product design, we have the specific and detailed expertise needed to produce the best electromagnetic interference (EMI) solutions essential to vehicle electronics. See the future of automotive wiring in a supplier that is interested in your success.
